- 产品描述
-
4W/8W端泵激光器
Application:
塑料等热敏感材料打标
Plastics and other heat-sensitive materials marking
- 产品特性
-
4W/8W端泵激光器
Solid State Q-switched Pulse Laser
Specifications:
Model
GYEP-1064-005
GYEP-1064-008
Wavelength
1064±1nm
Output power
>4W
>8W
Pulse duration
≈8ns
Frequency
≈30kHz(Uncontrollable)
Input Power
DC12V(150W)
DC12V(200W)
Beam Diameter
7±1mm
Red light indication
Inside
Cooling method
Air-cooling
- 技术参数
